Spindle diameter (hardened)
40/50 mm
Cutting circle 1st bottom
125 – 180 mm
Cutting circle in the other horizontal spindles
125 – 200 mm
Cutting circle vertical spindles
Top head air loaded receding chip breaker
Axial movement for horizontal spindles
22 mm
Axial movement for vertical spindles
Adjustment range for in-feed bed plate and fence
10 mm
Axial brakes for spindles: pneumatic
Outboard bearing for 2nd top and 2nd bottom horizontal spindles.
Right vertical spindle with straight/profile jointer.
Left vertical spindle with straight/profile jointer.
2nd top horizontal spindle with straight and profile jointers.
2nd bottom horizontal spindle with straight and profile jointers.
Pneumatic clutch
In-feed table length
1.200 mm
Hard chromed bed plates and fences for longer service life under extreme conditions, like for example MDF. Deep hard chromed: not just a flash
Bed plates exchangeable and adjustable to tooling
Air loaded feed rolls
Upper and lower driven feed rolls at the entrance
Feed rolls diameter
140 mm
Cardan drive system
Remote controls for emergency stop feed, jog and feed works
